Oil Filter
Product DescriptionSpecification Model Flow Capacity (M3/H) Power (KW) Weight (KG) Dimension (MM) W*L*H Diameter of Inlet/Outlet JYOP-A1
Product Description
Specification
| Model | Flow Capacity (M3/H) | Power (KW) | Weight (KG) | Dimension (MM) W*L*H | Diameter of Inlet/Outlet |
| JYOP-A1 | 1 | 1.1 | 160 | 500*800*1500 | 1 inch/DN25 |
| JYOP-A3 | 3 | 1.5 | 190 | 600*950*1550 | 1 inch/DN25 |
| JYOP-A5 | 5 | 3.0 | 230 | 800*1200*1600 | 1.5 inch/DN40 |
| JYOP-A10 | 10 | 4.0 | 300 | 900*1360*1680 | 2 inch/DN50 |
| JYOP-A20 | 20 | 7.5 | 380 | 1100*1420*1700 | 2.5 inch/DN65 |
| JYOP-A30 | 30 | 11.0 | 460 | 1300*1600*1750 | 3 inch/DN80 |
| JYOP-A50 | 50 | 22 | 600 | 1500*1700*1800 | 4 inch/DN100 |
Technical Specifications:
1.Suitable oil：Diesel,aviation kerosene,gas oil
2.Unsuitable oil：Emulsified diesel oil,diesel oil decolorization,water-containing diesel
3.Application：small oil depot,gas station,petrol station for transportation company,diesel used in the construction site or for the construction vehicles,generator,aviation kerosene,mine-owned diesel depot
4.Flow process: Multi stage filtration.It needs to change the consumption materials
5.Filtration precision: 200--50nm ultrafiltration.98% impurities can be caught.
6.Filtering material: It needs to be cleaned and to be used again and again.
7.Pressure monitoring: Automatic pressure monitoring device to monitor the filtration pressure any time to avoid overload operation of the feeding pump.
8.Filtration pressure：0.2-0.3Mpa/low pressure filtration,stable flow rate,stable
filtration effect.The filtered oil is clear and transparent.
9.Power: Customized
